功用与概述：Purpose and introduction

滤油机适用性于对30-500ML品类钢化塑瓶子、塑瓶的包装封膜。选择经济往来联系式汽缸通过包装，电磁波自由振荡送盖，都也可以轧盖(重金属式)或旋盖(塑盖)封膜，都也可以和前后轮的产生制作工艺装置连结組成产生线，不仅如此都也可以采购百级层流罩。This machine is suitable for the filling and sealing of 30-500ml series glass bottles and plastic bottles. The reciprocating between piston filling, electromagnetic oscillation send cover, cover (metal) can be rolled or screw cap (plastic cap) sealing. Can produce and the produce of the process equipment before and after connecting line. In addition, the laminar flow hood is available for selection.

结构特征：characteristic

装量精确性，杜尽渗漏。缺瓶不灌装线。 直流变频空调变频调速。 自觉展现计数法副作用。 整个机械均按GMP需要来设计。The filling amount is accurate, as Du drip. Lack of bottle does not fill. Frequency control of motor speed. Active display count. The machine according to the GMP request design.

水平性能指标/technical parameters：

型号 model	NQGX30-500
应用的规格Cutting dimension	30-500ml
出产地效率Production capacity	80-200瓶/分（罐/分种）80-200 bottles/min (cans/min)
装罐精确 Filling accuracy	≤±1%
电源线 Power	380V/50Hz
旋（轧）盖率Spin (rolling) cover rate	≥99%
功率power	3.0 kw
机械设备制造净含量 Machine weight	1500 kg
外形尺寸 boundary dimension	3000*1100*1700mm
