使用与概述/Brief Introduction：

机械选取很大三通管装灌阀，适使用在于水剂和膏霜类服务的装灌，很大对高粘稠度原辅材料清单（如浓酱、香辛料酱、番茄酱、种衣剂、微乳剂、透明桌面剂等）的疗效较好强烈，且精度等级高。机械选取PLC可代码编程调控，配上6英尺触碰屏人与机器用户界面机系统，实施运行自然进瓶，自然装灌，自然出瓶，电器元件，气动系统元组件均选取国.际高端品牌，确定了出彩的产品质量和坚持下去稳定性的耐热性。本专用机械空间结构简略，操作流程便捷，是目前中国理想的的涉及高粘稠度原辅材料清单的装灌专用机械。机械装备了解决办法漏滴与压模的装灌闷头，确定装灌重新后无漏滴，无压模。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

的特点/Characteristic：

◆掌握体系——选择三凌PLC掌握体系，灌装生产线标准容量js随机数调节。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆操作步骤使用接面——6厘米彩屏手触式操作步骤使用接面，形象化简略、安会不靠谱Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆功效调整——切料有防渗漏装置设备，可基于废料因素应有下潜分装功效。（此功效能选择）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电子元器件封装元器件封装——均用于展览着名店牌，狠抓环保设备的很安全信得过、合理高；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆自动化设备零控制部件——机械零控制部件均适用更优质304不锈不锈钢管钢板网作,如果是需要接触性货物可以适用316L另计算用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆计算检查——及时计算，对的工作生产产量主观反映落实。Counting test, real-time, intuitive reflect the yield of work.◆分装检则——无瓶不灌、瓶数不不灌Bottle filling test - no bottle no filling, not enough◆维保情况发生——该设备按照GMP特殊要求，可轻轻松松拆装工作、刷洗维保。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆掉换尺寸外形尺寸——根换罐装尺寸外形尺寸时，只需要简短调低，快速玩转信用卡。Changing specifications - change the filling specifications, simply adjust, easy fix.◆的节能运行环境——运行环境了的节能的框架，使仪器的运营环境非常绿色环保安全。（此的节能运行环境会标准配置）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

技术应用基本参数/technical parameters：

分装头数The number of filling head	8头（可选择4、6💃、8、10、16个分装头）8 head (optional 4, 6, 8, 10, 12 filling head)
应用瓶径 Applicable bottles Drive	Ф33-Ф100 mm
测量精度等级measure precision	±1%
罐装余量Canned capacity	150-1000ml
制造本事Production Capacity	2400-4000瓶/小时左右2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
