使用与间介/Brief Introduction：

半自行的式液压泵式膏体酱灌装线设备机我就是工司满足的市场消费需求開發的新货品。机械分为SUS304不锈钢304液压泵式的计量泵强制执行灌装线设备，且集自行的式上盖、自行的式旋盖、机电设备电力电气为混合式，第三产业常用，占地面的占地小，诸多技术应用于药业有限公司、面制品、农药杀虫剂、石油化工、化妆产品品等市场的固体包装箱，合乎GMP规定需求。Automatic plunger paste paste filling machine is my company to meet the market demand, introduction of foreign advanced technology to develop new products. This machine adopts SUS304 stainless steel plunger metering pump filling, cover and set for automatic, automatic screw cap, integration of the mechanical and electrical, economical and practical, cover an area of an area small, widely used in pharmaceutical, food, pesticides, chemical industry, cosmetics and other industries of liquid packaging, full compliance with GMP requirements.

显著特点/characteristic：

◆进行注塞泵式计量检定泵执行工作包装，常用各个浓稠度透明液体，精确高；泵的架构进行快接式拆御公司，容易清理、杀菌消毒。Adopt plunger type metering pump filling, used various viscosity liquid, high precision; The structure of pump adopts fast disassembly institutions, easy cleaning and disinfection◆齿轮泵式计量检测泵活赛环质材按照服务行业及溶剂物质的不一样的采取硅塑料，四氟乙稀或各种质材，比较特殊公开场合采取瓷砖质材。Plunger metering pump piston ring material according to the industry and different adopt silicon rubber, liquid ingredients tetrafluoroethylene or other material, special occasions with ceramic material◆PLC管控设计，变频器变频调速，自主化程度较高。PLC control system, frequency control of motor speed, a high degree of automation◆缺瓶不罐装，智能筛选功能性。Lack of bottle filling, automatic counting function◆装量参与调节方面，可是一次参与调节其他计量检定检验泵的充填量，也可造成其它计量检定检验泵参与微幅参与调节；操作流程用简，参与调节最快。The load adjustment is convenient, can be a filling quantity of all pumps also can be slightly adjusted according to various metering pump; Simple operation, rapid adjustment◆包装针头设置防漏滴装置设备，充填时前往瓶底包装，迟缓上升的，放置泡泡。Filling needles a drip-proof device, filling into the bottom of the bottle filling, slowly rising and prevent bubbles.◆机床可选用不一技术参数的塑料瓶子，的调整用简，可在短暂间内达成。The machine is suitable for various specifications of bottles, easy adjustment, it can be finished in a short period of time◆机器按GMP条件结构设计。The machine designed according to the requirements of GMP

技巧技术指标/technic parameter：

应用瓶里要求Size of bottles	20-1000ml（利用要定制）20-1000 - ml (according to your need）
实用矿泉水瓶直劲Apply the bottle diameter	¢20-¢150mm
实用盖子要求Apply the lid specifications	¢20-¢70mm
生产的工作能力 production capacity	四头装罐：1000-2500瓶/个钟头 Four filling head: 1000-2500 bottles per hour 八头分装：2500-4000瓶/分钟 Eight head filling: 2500-4000 bottles per hour 12头灌装线：4000-6000瓶/分钟 12 head filling: 4000-6000 bottles per hour
装量确定误差The load error	±1%
旋盖达标率Screw cover percent of pass	≥99%
电源模块power supply	380V，50HZ
输出power	3.0KW
氧气源gas sources	0.4-0.75MPA
强度调控speed control	变频柜可控硅调压variable speed
